Caterpillar excavator EC55/140/220/210/29 guide wheels, guide wheels, traveling tensioning wheels

Name: Caterpillar excavator EC5514022021029 guide wheels guide wheels traveling tensioning wheels
Brand: Caterpillar
Price: 80 USD

Wholesale Caterpillar excavator EC55/140/220/210/29 guide wheels, guide wheels, traveling tensioning wheels from china suppliers

Brand Name : Caterpillar

Model Number : EC55

Place of Origin : QUANZHOU.FUJIAN

MOQ : 100PCS

Price : US 80~150

Delivery Time : 20~25Days

Packaging Details : Export wooden pallets

Material : High-strength alloy cast steel

Color : Black and Yellow

Warranty Time : 2000 Hour

Key Words : Excavator Front Idler,Idler Assy,guide wheels

Finish : smooth

Package : Export wooden pallet

OEM Part No. : 8Y-0721

Contact Now

Product Details

The guide wheel of the Caterpillar E55 excavator is a precise and crucial chassis component. Its core is made of high-strength wear-resistant cast steel, and the key flange surface is quenched and hardened. It guides and restricts the track chain through precisely designed flanges and wheels, achieves low-resistance rotation through internal bearings/bushings and lubrication systems, and relies on an effective sealing system to resist external contamination. Its precise dimensions (such as the diameter of the shaft hole, the position of the installation hole, the width of the wheel, and the outer diameter) ensure a perfect match with the E55 chassis system. Regular lubrication maintenance and working condition inspection are the basis for maintaining its best performance and longest service life.

Caterpillar E55 Excavator Idler Wheel - Technical Data Sheet

1. Compatibility & Identification

Parameter	Specification
Machine Model	Caterpillar E55 Mini Excavator (Verify sub-model & s/n via equipment PIN)
OEM Part No.	8Y-0721 (Primary reference; critical to confirm via physical idler or PIN)
Aftermarket Ref.	ITR: GU1001 · Berco: 30500721 · Link-Belt: 3050-0721
Function	Guides upper track chain, maintains tension & alignment, absorbs operational shock

Caterpillar excavator EC55/140/220/210/29 guide wheels, guide wheels, traveling tensioning wheels

2. Material & Construction

Core Material: High-tensile cast steel (Grade ZG340-550, yield strength ≥550 MPa).
Wheel Rim: Induction-hardened surface (HRC 55-60), wear depth ≥5 mm.
Bearing System:
- Option A: Sealed needle roller bearings (DIN 5402).
- Option B: Bronze bushings (CuSn8P, oil-impregnated).
Sealing: Dual-lip steel-case seals + Nitrile O-rings (IP68-rated, -30°C to 120°C).
Lubrication: Central grease nipple (1/4" NPT), accepts lithium-complex grease (e.g., Cat GO-4).

3. Dimensional Specifications (mm)

Dimension	Value	Tolerance
Outer Diameter (Rim)	295	±0.5
Total Width (w/ flanges)	118	±0.3
Rim Gauge Width	98	±0.2
Bore Diameter (Shaft hole)	70	+0.02 / -0
Mounting Bolt Holes	2 × Ø18	H11
Bolt Circle Diameter (PCD)	120	±0.1
Net Weight	20.5 kg	-

4. Performance & Durability

Load Capacity:
- Static: 8,000 kg · Dynamic shock load: 15 kN (ISO 5683 compliant).
Service Life:
- Standard conditions: 3,000–5,000 hrs.
- Severe conditions (rock/abrasives): ≤1,500 hrs (lubricate every 10 hrs).
Operating Temp.: -40°C to +80°C (ambient).

5. Maintenance & Inspection

Lubrication Interval:
- Normal: 50 hrs (150g grease) · Severe: 20 hrs.
Wear Limits:
- Rim thickness wear >10% → Replace immediately.
- Flange height <15 mm → High derailment risk.
Track Tension: Maintain 30–50 mm sag (mid-span between carriers).

6. OEM vs. Aftermarket Guidance

Genuine CAT Identification:
- Laser-etched p/n 8Y-0721 + CAT logo on casting.
- Holographic anti-counterfeit label on packaging.
Aftermarket Selection:
- Require material certification (hardness, impact test per ASTM E23).
- Prioritize ISO 9001-certified manufacturers (e.g., ITR, Berco).
⚠️ Risk Alert: Non-genuine idlers may cause:
- Premature seal failure → Bearing contamination → Track misalignment.

7. Technical References

Installation: CAT SEBD0518-08 procedure.
Torque Specs: Mounting bolts – 380 ±20 N·m (lubricate threads).
Validation: Confirm compatibility via CAT SIS 2.0 using machine PIN.

For real-time inventory/pricing, provide equipment Product Identification Number (PIN) or physical idler measurements (bore, PCD, width).

Note:

Important note: When purchasing replacement parts, providing the exact model, serial number of the device or the part number on the old guide wheel is the only reliable way to ensure that you get a perfectly matched and reliable component. Dimensions and details may vary slightly due to manufacturing batches or different third-party suppliers.
